M5WC

A Cobot Mig Torch for high duty applications.

560A CO2 @ 100% Duty Cycle
1600W Cooler
540A Mixed Gas M21 @ 100% Duty Cycle
1600W Cooler
Wire Size 0.9-1.6mm

M5WC -Liquid-Cooled Cobot Mig Welding Torch

A double circuit Liquid-Cooled Mig torch ideal for high duty cobot applications.  Available with an adjustable torch bracket.

Make Work Life Easier

Massive Gains in Productivity!

Arc Wear Parts are more efficient and last longer!

  • Contact tips last up to 6 times longer
  • Nozzles last up to 3 times longer
  • Tip adaptors last up to 5 times longer

Technical Specification

Cooler Rating Max.A Pulse Max. Load
Liquid-Cooled
Rating: CO2 1600W 560A 24KW
1200W 540A 22KW
1000W 510A 20KW
Rating: Mixed Gas M21 1600W 540A 380A 22KW
1200W 520A 350A 21KW
1000W 500A 340A 19.5KW
Duty Cycle 100% 100%
Wire Size Filler Wires Fe, Fe-MC / FC 0.9-1.6mm
Filler Wires Ss, Ss-MC /FC 0.9-1.6mm
Filler Wires Al 1.0-1.6mm
Minimum Liquid Flow Rate 1.5 l/min
Minimum Liquid Inlet Pressure 2.5 Bar
Maximum Liquid Inlet Pressure 5.0 Bar
Maximum Liquid Inlet Temperature 50oC
Operating Temperature Range -10…+40oC

Downloads

Arc Auto – Cobot Series

Product Catalogue

Download
Arc M Liquid-Cooled Cobot

Set-Up Guide

Download
View all downloads

Key Elements

Wear Parts

Superior performance wear parts have pushed the performance levels way beyond currently accepted norms

Liners

From drive roll to contact tip every small detail that affects soft wire welding has been considered

Cable Sets

Clever material selection combines flexibility, durability and performance

Cobot Bracket

Secure, adjustable brackets available as an optional add-on

Key Benefits

  • Large area tapered face on contact tips improves current transfer.
  • Insulator ‘snap fits’ onto the tip adaptor to prevent accidental loss.
  • All wear parts are laser marked for ease of identification.

Key Benefits

  • Steel liners for steel wire, steel metal core and flux core wires
  • Stainless Steel liners for high duty steel applications, stainless steel, stainless steel metal core anf flux core wires.
  • Combi-liners for aluminium, stainless steel, stainless steel metal core and flux core wires
  • Soft wire liners for aluminium, aluminium alloy and copper alloy wires

Key Benefits

  • Power cables utilize superior grade copper conductors for added protection against poor water quality and contaminants
  • Specified and constructed to last over 1 million flexes in life cycle testing
  • Modular designed housing allows exit easy cable reconfiguration

Key Benefits

  • Secure, adjustable brackets compatible with both MIG and TIG auto/cobot torches
  • Engineered for automated and collaborative (Cobot) welding systems
  • Easily position the welding torch at multiple angles to suit the job

Core Technologies

Bi-Flow2 Technology

Lighter and cooler running torches with increased power to weight performance ratios

NRS Technology

Trouble free fitting and removal of the nozzle with a highly efficient transfer of heat between the base of the nozzle and the dual circuit chamber

SIC Technology

Accumulated spatter breaks free when the nozzle is released

Re-engineered high capacity cooling chambers remove excessive heat at source.

Nozzle, tip adaptor and contacts tips are all force cooled.

Nozzle Retention System
NRS Technology combines a Liquid-Cooled nozzle seat and a push-on nozzle with a threaded retention system.

The design solutions force cool the nozzle, aid spatter removal and increase front-end wear parts durability.

Spatter Isolation Chamber

A uniquely designed spatter “well” accumulates molten metal particles safely and works in conjunction with the nozzle retention system for trouble free removal of the nozzle and spatter ring.

In The Box

Standard Set-up
